Aluminum CNC Machining Service
Our Aluminum CNC Machining Service Material Choice
We machine twelve aluminum alloys—from versatile 6061-T6 to aerospace-grade 7075-T6 and precision-cast MIC-6—each optimized for specific applications. From general purpose to high-stress components, find the perfect aluminum grade for your requirements.
Aluminum 6061 is the most widely used aluminum alloy in manufacturing. It offers an excellent balance of strength, machinability, and weldability at an economical price point. This versatile alloy is corrosion-resistant, non-magnetic, and heat treatable, making it suitable for diverse applications from aircraft fittings to electronic enclosures.
Key Properties:
- Tensile Strength: 310 MPa (45,000 psi)
- Yield Strength: 276 MPa (40,000 psi)
- Elongation at Break: 17%
- Hardness: 95 Brinell
- Density: 2.70 g/cm³ (0.098 lb/in³)
- Elastic Modulus: 68.9 GPa (10,000 ksi)
Aluminum 7075 is a hard, high-strength alternative to 6061 Aluminum. It is often used for parts in high-stress applications, and is also corrosion-resistant, non-magnetic, and heat treatable. With strength comparable to many steels but at one-third the weight, 7075 is the material of choice for aerospace structures and high-performance components.
Key Properties:
- Tensile Strength: 572 MPa (83,000 psi)
- Yield Strength: 503 MPa (73,000 psi)
- Elongation at Break: 11%
- Hardness: 150 Brinell
- Density: 2.81 g/cm³ (0.101 lb/in³)
Aluminum 5052 is the most readily weldable of the high-strength aluminum alloys. It offers exceptional corrosion resistance, particularly against salt water and marine environments, making it the preferred choice for boat builders and offshore applications. This strain-hardened alloy provides moderate strength with excellent formability.
Key Properties:
- Tensile Strength: 228 MPa (33,000 psi)
- Yield Strength: 193 MPa (28,000 psi)
- Elongation at Break: 12%
- Hardness: 60 Brinell
- Density: 2.68 g/cm³ (0.097 lb/in³)
Aluminum 2024 is a high-strength copper-based alloy used extensively in the aviation industry. It offers excellent fatigue resistance and fracture toughness, making it ideal for structural components subjected to repeated stress cycles. While not weldable (riveting is preferred), 2024 delivers superior performance in applications where fatigue life is critical.
Key Properties:
- Tensile Strength: 483 MPa (70,000 psi)
- Yield Strength: 345 MPa (50,000 psi)
- Elongation at Break: 18%
- Hardness: 120 Brinell
- Density: 2.78 g/cm³ (0.100 lb/in³)
Aluminum MIC-6 is a cast aluminum tooling plate renowned for its exceptional flatness, dimensional stability, and stress-free structure. Unlike rolled aluminum plates, MIC-6 is continuously cast and stress-relieved, resulting in a material that maintains precise tolerances even after extensive machining. It is the preferred choice for precision tooling and applications requiring superior flatness.
Key Properties:
- Tensile Strength: 172 MPa (25,000 psi)
- Yield Strength: 105 MPa (15,000 psi)
- Elongation at Break: 3%
- Hardness: 65 Brinell
- Density: 2.70 g/cm³ (0.098 lb/in³)
Aluminum 7050 is a high-toughness aerospace alloy developed specifically for thick-section applications. It offers better stress-corrosion cracking resistance than 7075 while maintaining comparable strength, making it ideal for aircraft bulkheads and critical structural components. The T7451 temper provides excellent dimensional stability and residual stress relief.
Key Properties:
- Tensile Strength: 524 MPa (76,000 psi)
- Yield Strength: 469 MPa (68,000 psi)
- Elongation at Break: 11%
- Hardness: 135 Brinell
- Density: 2.83 g/cm³ (0.102 lb/in³)
Aluminum 6063 is an extrusion alloy optimized for architectural and ornamental applications. It offers good strength with excellent surface finish capability and superior corrosion resistance, making it ideal for anodizing and decorative treatments. This alloy is more formable than 6061 but offers slightly lower strength, providing the perfect balance for architectural trim and consumer products.
Key Properties:
- Tensile Strength: 241 MPa (35,000 psi)
- Yield Strength: 214 MPa (31,000 psi)
- Elongation at Break: 12%
- Hardness: 73 Brinell
- Density: 2.70 g/cm³ (0.098 lb/in³)
Aluminum 6082 is the European equivalent to 6061, offering similar properties with slightly higher strength. It is commonly used in structural applications throughout Europe and provides excellent corrosion resistance, good weldability, and superior machinability. This versatile alloy is widely specified in European engineering standards.
Key Properties:
- Tensile Strength: 310 MPa (45,000 psi)
- Yield Strength: 260 MPa (38,000 psi)
- Elongation at Break: 10%
- Hardness: 95 Brinell
- Density: 2.70 g/cm³ (0.098 lb/in³)
Aluminum 6060 is a medium-strength extrusion alloy offering good corrosion resistance and excellent surface finish characteristics. It is particularly well-suited for complex extruded profiles and decorative applications where anodizing quality is important. With slightly lower strength than 6061, this alloy provides enhanced formability.
Key Properties:
- Tensile Strength: 215 MPa (31,000 psi)
- Yield Strength: 170 MPa (25,000 psi)
- Elongation at Break: 14%
- Hardness: 70 Brinell
- Density: 2.70 g/cm³ (0.098 lb/in³)
Our Aluminum CNC Machining Surface Finishing Choice
We offer complete finishing capabilities—from as-machined and bead blasting to Type II/III anodizing and powder coating—each delivering specific functional or aesthetic properties. From corrosion protection to decorative colors, find the perfect finish for your aluminum parts.
As Machined
This is the default finish directly from the CNC machine. Tool paths and marks are visible. It’s ideal for functional or internal components where appearance isn’t a priority. Cost-effective and fast, this finish is often used for prototypes and parts not requiring surface refinement.
Bead Blasting
Bead blasting creates a uniform matte texture by propelling fine glass beads at the aluminum surface. This process removes tool marks and produces a consistent, non-reflective appearance across the entire part. It’s commonly used when parts require a professional look without the cost of anodizing.
Tumbling Finish
Tumbling smooths sharp edges and burrs through mechanical abrasion in a vibratory bowl. Parts tumble with ceramic media, creating a soft, consistent finish while rounding corners and improving surface uniformity. This process works well for small to medium-sized parts requiring edge break and aesthetic improvement.
Polishing
Polishing produces a smooth, reflective surface through progressive abrasive techniques. This finish ranges from semi-bright to mirror-like depending on the level of polishing applied. It’s ideal for decorative applications, optical components, or parts requiring minimal surface roughness for functional reasons.
Anodizing Type II (DECORATIVE)
Anodizing Type II grows a controlled oxide layer on the aluminum surface through an electrochemical process. This layer provides corrosion protection and accepts dyes for color options including clear, black, red, blue, and gold. The coating thickness ranges from 0.0002″ to 0.001″ and integrates into the aluminum structure rather than sitting on top.
Anodizing Type III HARDCOAT
Anodizing Type III creates a thicker, harder oxide layer than Type II, significantly improving wear resistance and durability. This process typically produces a black or natural gray finish and is commonly specified for parts subjected to abrasion or harsh environments. The coating thickness ranges from 0.001″ to 0.004″.
Alodine/Chromat
Alodine (chromate conversion coating) provides corrosion protection while maintaining electrical conductivity. This thin chemical coating appears clear or gold and serves as an excellent base for paint or as a standalone protective finish. It’s commonly used in aerospace and military applications where conductivity must be preserved.
Powder Coating
Powder coating applies dry powder electrostatically, then cures it under heat to form a durable, uniform finish. This process offers unlimited color options, excellent impact resistance, and superior corrosion protection. The coating thickness typically ranges from 0.002″ to 0.010″ and provides both aesthetic appeal and functional protection.
Electroless Nickel Plating
Electroless nickel plating deposits a uniform nickel-phosphorus coating through chemical reduction rather than electrical current. This process provides exceptional corrosion resistance, wear protection, and consistent coverage even in complex geometries and internal passages. The coating appears semi-bright gray and offers excellent lubricity.
Laser Marking
Laser marking permanently marks aluminum surfaces with text, logos, serial numbers, or 2D barcodes without adding material or changing dimensions. This non-contact process creates high-contrast marks that resist wear and environmental exposure. It’s ideal for traceability requirements and branding applications where permanent identification is essential.
Our Aluminum CNC Machining Services Capabilities
Complete CNC machining services including precision milling (3-axis, 4-axis, 5-axis) and turning with tolerances to ±0.0005″. From simple brackets to complex aerospace components with tight tolerances and superior surface finishes.
CNC Machining Service
CNC Turning Service
CNC Milling Service
Industries And Applications Of Precision CNC Machined Aluminum Parts
Trusted aluminum machining partner across aerospace, medical devices, automotive/EV, electronics, industrial equipment, and R&D sectors. Delivering critical components that meet the most demanding specifications in each industry.
Aerospace & Defense
Aluminum components in aerospace applications demand exceptional reliability and precise performance under extreme conditions. Our AS9100 certified manufacturing ensures every part meets stringent aerospace quality standards.
Medical Devices
Medical applications require exceptional precision, complete traceability, and compliance with rigorous regulatory standards. Our ISO 13485 certified processes support life-saving medical equipment through reliable performance and consistent quality.
Automotive & Electric Vehicles
The automotive industry, especially electric vehicles, relies on aluminum for lightweight structural components and heat management. We support this rapidly growing sector with components enabling weight reduction and improved efficiency.
Electronics & Telecommunications
Aluminum's excellent thermal conductivity and EMI shielding properties make it essential for electronic enclosures and heat sinks. We produce precision components that enable efficient thermal management in modern electronics.
Why Choose Us for Your Copper CNC Machining Needs?
Rapid Prototyping Available
Need it fast? Our 3–5 day rapid prototyping service gets functional prototypes in your hands quickly for testing and validation.
Complete In-House Manufacturing
50+ CNC machines under one roof means faster turnaround, better quality control, and no outsourcing delays. You work directly with the people making your parts.
No Minimum Order Quantity
From 1 prototype to 10,000 production parts, we provide the same precision and care. Perfect for startups, R&D teams, and established manufacturers alike.
Full CMM Inspection Included
Every order includes dimensional verification using Coordinate Measuring Machines. First article inspection reports (FAIR) available at no extra charge.
CNC Copper Parts Made Simple
Get 10-day standard lead times on custom copper components. Upload your drawings to see how we can deliver precision for your application.
Our ordering process
Request for quote
Share project details for competitive pricing
Quote and design analysis
Detailed quote with design evaluation
Production
Precision manufacturing with advanced CNC systems
Quality control
Rigorous inspections ensure specifications
Delivery
Reliable shipping worldwide
About Us
Since 2012, we've been at the forefront of CNC machining, initially specializing in manufacturing precision molds and evolving to provide comprehensive in-house production of machined parts. This journey has allowed us to complete over 1270 custom projects, equipping us with extensive experience in overcoming diverse machining challenges. We continuously refine our techniques, ensuring optimal quality for every component.
Our Commitment to Your Success:
-
17+ Years of Expertise: Our deep specialization in machining production across various industries enables efficient problem-solving and innovation.
-
Self-Owned Workshop: Our in-house machining facility significantly shortens production cycles and reduces your procurement costs by at least 10%.
-
Unwavering Confidentiality: We prioritize the utmost confidentiality for your designs and intellectual property, always signing protection agreements.
-
Real-Time Order Tracking: Stay informed with continuous production updates throughout your order's journey.
Factory Photo
Brass CNC Machining Frequently Asked Questions (FAQs)
What aluminum alloy should I choose for my part?
The right aluminum alloy depends on your specific application requirements.
- Aluminum 6061-T6 – Most versatile for general purpose, good strength and machinability
- Aluminum 7075-T6 – Maximum strength for high-stress aerospace applications
- Aluminum 5052 – Superior corrosion resistance for marine environments
- Aluminum 2024-T3 – Excellent fatigue resistance for repeated stress cycles
- Aluminum MIC-6 – Exceptional flatness for precision tooling and fixtures
Our engineering team can recommend the optimal alloy for your application.
How long does custom CNC machining take?
- Rapid Prototyping: 3-5 business days
- Standard Production: 10-15 business days
- High-Volume Production: 3-4 weeks
Can you machine complex geometries and undercuts?
Five-axis CNC machining handles deep pockets, compound curves, and features on multiple faces in single setups.
Internal undercuts may require specialized tooling, EDM, or design modifications. Upload your CAD file for manufacturability assessment.
Do You Offer Finishing Services for Brass Parts?
Yes. We provide complete brass finishing including deburring, polishing, plating (nickel, chrome, tin, silver, gold), powder coating, passivation, and custom finishes.
Why does aluminum offer advantages for CNC machining?
Aluminum offers specific benefits that simplify and improve the process of CNC machining. Many grades of aluminum can be effectively penetrated with cutting tools. Aluminum will chip easily and is relatively easy to shape, making aluminum three times faster to machine than iron or steel.
Other benefits include:
- Machinability
- Corrosion resistance
- Strength-to-weight ratio
- Electrical conductivity
- Anodization potential
- Recyclability
